Picking the right motherboard for the latest AMD processors is essential in ensuring a robust gaming performance. A top-quality motherboard directly affects the speed and responsiveness of your gaming setup.
This is where the X870 and X870E chipsets come in. They include advanced features such as advanced I/O, robust VRM, DDR5, and PCIe Gen 5 support, all of which are suitable for successful AMD gaming.
Do you want to buy a chipset for your rig? This guide discusses the best X870 motherboards 2025 and top X870E suggestions. By the end of this guide, you will be equipped with the knowledge of AM5 motherboards for your next gaming PC build.
Top-Rated X870 Motherboards
1. ASRock X870 Steel Legend WiFi
The ASRock Steel Legend is all about gaming performance and aesthetics. It includes a white theme plus a solid VRM setup. The motherboard delivers both stability and style. If both looks and performance are of priority to you, then this Steel Legend serves as one of the best motherboards for AM5 socket.
Features
- A-RGB White Design
- M.2 heatsinks
- 14+2+1 VRM design
- 20 USB ports, USB 4 included
- Up to 8,000+ MT/s DDR5 support
-
WiFi 7, 2.5G LAN, Bluetooth 5.4
2. MSI MAG X870 TOMAHAWK WiFi
For a budget option, the MSI MAG X870 TOMAHAWK is a great option. It consists of stable VRM, rapid memory support, and DIY tools. This is an excellent value choice for beginners and those advancing from older systems.
Features
- 14+2+1 VRM phase design
- Toolless M.2 installation
- 20 USB ports, including USB4
- 4x M.2 slots and 4x SATA III
- Up to 8,400+ MT/s DDR5 support
-
WiFi 7, Realtek 5G LAN, and Bluetooth 5.4
3. GIGABYTE X870 AORUS Tachyon ICE
Merging top performance with an efficient build, the AORUS Tachyon ICE is a top-notch overclocking motherboard. It consists of excellent memory tuning plus LN2 cooling. This model is a top option for gamers looking for the best performance.
Moreover, the Tachyon ICE is a perfect option for gamers aiming for top scores or pushing their computer to the limit.
Features
- SPS 18+2+2 Digital Power Phase
- 9000+ MT/s OC optimized memory layout
- OC-friendly LN2 cooling
- Dual M.2 Gen 5 and 6x SATA III
-
Includes WiFi 7, 10GbE LAN, Bluetooth 5.4
X870E Motherboards for AMD Ryzen
1. ASRock Phantom Gaming X870E Nova WiFi
The ASRock Phantom Gaming X870E Nova WiFi is a special motherboard that provides great heat performance and expanded connections. It is a highly capable X870E motherboard for gamers who are looking to build on the latest AMD platform.
Features
- 20+2+1 phase power delivery
- VRM temperatures reach only 53°C while testing
- 21 total USB ports (9 front and 12 rear), including 2 USB4 ports
- 5x M.2 slots (1x Gen3) plus 4x SATA III storage
- DDR5 up to 8,200+ MT/s
- WiFi 7, Realtek 5G LAN, Bluetooth 5.4
- RGB lighting system
-
HDMI 2.1 and dual USB4 port video outputs
Recommended: Best Gaming Motherboards Sorted by Socket & Chipset
2. MSI MPG X870E CARBON WiFi
Another great performance AM5 motherboard for gaming 2025 is the MSI MPG X870E, which is the best option for gaming enthusiasts going for strong features plus a smooth design. It includes smart DIY tools, speedy memory support, as well as strong overclocking abilities.
Features:
- 18+2+1 VRM phase design
- Smart Button and MSI AI Boost
- 22 USB ports with 2 USB4 ones
- DDR5 up to 8,400+ MT/s
- 4x M.2 slots and 4x SATA III
- WiFi 7, dual LAN, Bluetooth 5.4
-
HDMI 2.1 and DisplayPort 1.4
3. ASRock X870E Taichi Lite
The Taichi Lite is optimized for hardcore gamers pushing towards maximum performance. If you are looking for a peak-level overclocking X870E motherboard that includes 24+2+1 phase VRMs, PCIE Gen 5, and increased USB Support, then this ASRock motherboard is the right choice for you.
Features
- 24+2+1 phase VRM, 110A SPS
- Advanced heat management
- 21 USB ports
- 4x M.2 (with PCIe 5.0) and 6x SATA III
- Up to 8,200+ MT/s DDR5 support
-
WiFi 7, Realtek 5G LAN, and Bluetooth 5.4
4. ROG Crosshair X870E Extreme
The ROG Crosshair Extreme is a premium build for serious gamers aiming for peak performance, heat control, and futuristic connection. The build includes strong input-output options plus overclocking power.
Features
- 20+2+2 power stages (110A)
- Huge heatsinks and dual 8-pin EPS power
- Three PCIe 5.0 M.2 slots
- 2x M.2 via DIMM.2 and 6x SATA III
- DDR5 memory support up to 256GB, AMD EXPO, and NitroPath tuning
- Dual LAN (10G and 5G), WiFi 7, Bluetooth 5.4, and 2x USB4 Type-C ports
-
Customizable 5-inch OLED LiveDash, AI cooling, plus Aura Sync RGB lighting
X870 vs X870E Comparison
The table shows the X870 and X870E chipsets' features comparison of AM5 motherboards to further aid you in your buying decision and performance needs.
|
Feature |
X870 |
X870E |
|
PCIe Version |
Gen 5 |
Gen 5 |
|
USB Support |
USB 3.2 Gen 2x2, USB4 (select) |
More USB4 ports |
|
Power Delivery |
Up to 18+2+1 |
Up to 24+2+1 |
|
Network Connectivity |
WiFi 7, 2.5G LAN |
WiFi 7, 5G/10G LAN |
|
Form Factor Variety |
ATX and Micro-ATX |
Mostly ATX and E-ATX |
|
Overclocking Capability |
Moderate |
Top-grade, enthusiast-level |
Conclusion
In summary, the best motherboard for Ryzen 9000 depends on blending cutting-edge features with its continuing value. If you require top-grade performance, the X870E takes top spot with better connectivity, thermal design, as well as overclocking, in comparison with the X870E series.
The X870E and X870 motherboard buyers’ guide has listed models to aid you in deciding what is best for you. Regardless of being a hardcore gamer or a gaming PC builder, picking the correct motherboard to match your requirements ensures your system works to its full potential.
FAQs
Q: Is X870E better than X870 for AMD Ryzen CPUs?
Yes, the X870E is comparatively better than the X870 chipset, specifically the Ryzen 9000 series. X870E provides full PCIe 5.0 support for both GPU and storage. It includes stronger power delivery and enhanced I/O, such as extra USB4 ports.
Q: What is the difference between X870 and X870E motherboards?
X870E motherboards usually include PCIe Gen 5 support for both the GPU and NVMe storage. On the other hand, X870 chipset motherboards may only provide Gen 5 for storage. X870E models also feature better power delivery, enhanced VRMs, and additional USB4 ports.
Q: What does the E mean in X870E?
The "E" in X870E stands for "Enhanced," which indicates a more premium version of a motherboard within the X870 chipset family.
Q: Is the X870 chipset worth it?
The X870 chipset is an excellent choice for Ryzen 9000 builds, providing PCIe 5.0 storage, USB4 for some models, plus stable connectivity. It is more affordable than X870E. However, its cheaper cost doesn’t stop it from delivering next-gen performance for gamers and also content creators.
Q: What processors are compatible with X870E?
The X870E chipset is compatible with the AMD Ryzen 9000 series processors, which are built on the new Zen 5 architecture. Due to its AM5 socket, it also supports the Ryzen 7000 series (Zen4). This makes the X870E a versatile option for both present and next-gen Ryzen chips.
Q: Does the X870 have built-in WiFi?
Yes, many X870 motherboards consist of built-in WiFi, often WiFi 7. However, its availability is dependent on the specific model. Therefore, one must always go through the manufacturer's specifications.
