Is it the AMD RX 7600 XT or the Nvidia RTX 4060 Ti? To know which GPU is the best choice for you, let's understand their main distinction first, the RX 7600 XT is a part of AMD’s Radeon RX 7000 Series, while the Nvidia RTX 4060 Ti is part of the GeForce RTX 4060 series GPUs.
Moving on, both are high-range and mid-range graphics cards, respectively. Both have their own features and performance capabilities. While both support 1080p and 1440p gaming, they have their own specifications that make them suitable for different audiences. Hence, choosing between the two relies upon your preferences and budget.
The guide below provides an overview of both products, with their specifications, benchmarks, and gaming performance.
Now, let’s look at the RX 7600 XT review and RTX 4060 Ti review.
Market Overview and Specifications
The 7600 XT GPU was released on January 24, 2024, while the RTX 4060 Ti launched its 8GB model on May 24, 2023. Its 16 GB model was released on July 18, 2023. The RX 7600 XT was launched at a retail cost of $329, while its counterpart was at $399. The 16GB model was priced at $499.
RX 7600 XT vs RTX 4060 Ti comparison
The table below shows the 7600 XT vs 4060 Ti specs of the 16GB versions of both GPUs. This ensures a side-by-side comparison of both graphics cards based on the same VRAM.
|
Specs |
RX 7600 XT (16GB) |
RTX 4060 Ti (16GB) |
|
Architecture |
RDNA 3 |
Ada Lovelace |
|
Process Node |
TSMC 6nm |
TSMC 4N (5nm) |
|
Stream / CUDA Cores |
2048 stream processors |
4,352 CUDA cores |
|
Ray Tracing Cores |
32 ray accelerators |
34 3rd-gen RT cores |
|
Tensor / AI Cores |
64 AI accelerators |
136 4th-gen Tensor cores |
|
Base Clock |
Up to 2470 MHz |
2310 MHz |
|
Boost Clock |
Up to 2755 MHz |
2535 MHz |
|
VRAM |
16 GB GDDR6 |
16 GB GDDR6 |
|
Memory Speed |
18 Gbps |
18 Gbps |
|
Memory Bus Width |
128-bit |
Same |
|
Memory Bandwidth |
Up to 288 GB/s |
Same |
|
Cache |
32MB Infinity Cache |
32MB L2 Cache |
|
PCIe Interface |
PCIe 4.0 x16 |
PCIe 4.0 x8 |
|
TDP |
190W |
165W |
|
Power Connector |
1x 8-pin |
Same |
|
Upscaling Support |
AMD FSR 2 / FSR 3 |
DLSS 3 with Frame Generation |
|
Ray Tracing Support |
Yes |
Yes |
|
AV1 Encode/Decode |
Yes |
Yes |
Performance Overview and User Benchmarks
Geforce RTX 4060 Ti (16 GB) provides better performance over the RX 7600 XT (16 GB) in benchmarks and user scores, due to stronger architecture, higher core counts, plus DLSS or frame generation support.
Overall, the RTX 4060 Ti has more effective 3D speed against the RX 7600 XT and around 29% higher performance as a whole. RTX 4060 Ti ray tracing capability is higher than that of the RX 7600 XT.
At 1440p, the average frame rate is approximately 86 FPS on the RTX 4060 Ti, compared to 68 FPS on the RX 7600 XT.
In accordance with thermal performance, the RX 7600 XT power consumption is at 190W TDP, which requires moderate cooling and a 500 to 600W PSU for total stability.
AMD 7600 XT vs Nvidia 4060 Ti Benchmark Comparison Table
|
Metric |
RX 7600 XT (16 GB) |
RTX 4060 Ti (16 GB) |
Advantage |
|
Effective 3D Speed |
~49.6% |
~60.9% |
RTX 4060 Ti (+23%) |
|
Average FPS at 1440p |
~68 FPS |
~86 FPS |
RTX 4060 Ti (+25-32%) |
|
GeekBench 6 Compute |
~86K |
~135K |
RTX 4060 Ti (+56%) |
|
Aggregate Synthetic Score |
~40 |
~53 |
RTX 4060 Ti (+32.5%) |
Gaming Performance
This table compares RX 7600 XT vs RTX 4060 Ti gaming performance across 1080p and 1440p settings.
|
Game |
RX 7600 XT (16 GB) |
RTX 4060 Ti (16 GB) |
Upside for RTX 4060 Ti |
|
Cyberpunk 2077 |
~55-60 FPS |
~6-70 FPS |
~10-15% |
|
Forza Horizon 5 |
~85 FPS |
~90-95 FPS |
~6-10% |
|
Far Cry 6 |
~70 FPS |
~75 FPS |
~7% |
|
Hogwarts Legacy |
~80 FPS |
~85 FPS |
~5-6% |
|
Shadow of Tomb Raider |
~60 FPS |
~65 FPS |
~8% |
|
The Witcher 3 |
~75-80 FPS |
~80-85 FPS |
~5-7% |
Across modern AAA and competitive titles, the RTX 4060 Ti (16 GB) delivers a significant performance benefit over the RX 7600 XT, at higher resolutions and in games that support DLSS or ray tracing. While both cards handle 1080p, the 4060 Ti offers smoother gaming, better future-proofing, and constantly higher frame rates.
Conclusion
The RTX 4060 Ti (16 GB) offers better overall performance compared to the AMD RX 7600 XT (16 GB). It’s suitable for gamers looking for smoother 1440p gameplay and futuristic features. On the other hand, the RX 7600 XT is a solid option for users on a budget who aim for 1080p gaming, delivering good value without any enhanced upscaling.
For performance and long-term capability, go with the RTX 4060 Ti. If budget matters more, choose the RX 7600T.
FAQS
Q: Which GPU is better for 1080p gaming - RX 7600 XT or RTX 4060 Ti?
At the 1080p gaming GPU comparison, the RTX 4060 Ti is better for 1080p gaming, delivering 10 to 20% higher frame rates.
Q: Which GPU is better RX 7600 XT or the RTX 4060 Ti?
The RTX 4060 Ti outperforms the RX 7600 XT by offering better ray tracing, DLSS 3 support, and higher power efficiency. However, the RX 7600 XT is a good budget choice for 1080p gaming. Overall, 4060 Ti is a better long-term investment.
Q: What about power consumption in AMD RX 7600 XT vs Nvidia RTX 4060 Ti?
The RX 7600 XT includes a TDP of 190W, while the RTX 4060 Ti is more power-efficient at 165W. It provides better performance per watt and less heat or thermal output.
Q: Which card gives better value in 7600 XT vs 4060 Ti Price?
As a budget user, the 7600 XT offers a better price-to-performance ratio at 1080p. If you want longevity and stronger features, then the 4060 Ti GPU gives better value in the long term.
Q: What is the Best GPU under $400?
Both AMD Radeon RX 7600 XT and NVIDIA GeForce RTX 4060 Ti were considered one of the best GPUs under $400, at 3 and 4, respectively.
